Product Summary
The XC3SD1800A-4CSG484C is a Field-Programmable Gate Array (FPGA). It solves the design challenges in most high- volume, cost-sensitive, high-performance DSP applications. The XC3SD1800A-4CSG484C offers densities ranging from 1.8 to 3.4 million system gates.
Parametrics
XC3SD1800A-4CSG484C absolute maximum ratings: (1)VCCINT, Internal supply voltage: –0.5 to 1.32 V; (2)VCCAUX, Auxiliary supply voltage: –0.5 to 3.75 V; (3)VCCO, Output driver supply voltage: –0.5 to 3.75 V; (4)VREF, Input reference voltage: –0.5 to VCCO+0.5 V; (5)VIN, Voltage applied to all User I/O pins and Dual-Purpose pins Driver in a high-impedance state:–0.95 to 4.6 V; (6)Voltage applied to all Dedicated pins: –0.5 to 4.6 V; (7)IIK, Input clamp current per I/O pin: ±100mA; (8)VESD, Electrostatic Discharge Voltage: ±2000 V; (9)TJ, Junction temperature: 125℃; (10)TSTG, Storage temperature: –65 to 150℃.
Features
XC3SD1800A-4CSG484C features: (1)Very low cost, high-performance DSP solution for high-volume, cost-conscious applications; (2)250 MHz XtremeDSP DSP48A Slices; (3)Hierarchical SelectRAM memory architecture; (4)Dual-range VCCAUX supply simplifies 3.3V-only design; (5)Suspend, Hibernate modes reduce system power; (6)Low-power option reduces quiescent current; (7)Multi-voltage, multi-standard SelectIO interface pins; (8)Abundant, flexible logic resources; (9)Eight low-skew global clock networks, eight additional clocks per half device, plus abundant low-skew routing; (10)Configuration interface to industry-standard PROMs; (11)MicroBlaze and PicoBlaze embedded processor cores; (12)BGA and CSP packaging with Pb-free options; (13)XA Automotive version available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 XC3SD1800A-4CSG484C |
|
SPARTAN-3ADSP FPGA 1800K 484CSA |
Data Sheet |
|
|
||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||
 |
XC3S1000 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||
|
XC3S1000-4FG456I |
|
IC FPGA SPARTAN 3 456FBGA |
Data Sheet |
|
|
||||||||||
|
XC3S1000-4FG676I |
|
IC FPGA SPARTAN 3 676FBGA |
Data Sheet |
|
|
||||||||||
|
XC3S1000-4FGG320C |
|
SPARTAN-3A FPGA 1M STD 320-FBGA |
Data Sheet |
|
|
||||||||||
|
XC3S1000-4FGG320I |
|
IC SPARTAN-3A FPGA 1M 320-FBGA |
Data Sheet |
|
|
||||||||||
|
XC3S1000-4FGG456C |
|
IC SPARTAN-3 FPGA 1M 456-FBGA |
Data Sheet |
|
|
||||||||||
