Product Summary
The XC6SLX45T-3FGG484C is an FPGA.
Parametrics
XC6SLX45T-3FGG484C absolute maximum ratings: (1)VCCINT, Internal supply voltage relative to GND: –0.5 to 1.32 V; (2)VCCAUX, Auxiliary supply voltage relative to GND: –0.5 to 3.75 V; (3)VCCO, Output drivers supply voltage relative to GND: –0.5 to 3.75 V; (4)VBATT, Key memory battery backup supply: –0.5 to 4.05 V; (5)VFS, External voltage supply for eFUSE programmin: –0.5 to 3.75 V; (6)VREF, Input reference voltage: –0.5 to 3.75 V; (7)VIN, I/O input voltage relative to GND (user and dedicated I/Os): –0.95 to 4.4 V; (8)VTS Voltage applied to 3-state output (user and dedicated I/Os): –0.95 to 4.4 V; (9)TSTG Storage temperature (ambient): –65 to 150℃; (10)TSOL, Maximum soldering temperature: +260℃; (11)TJ, Maximum junction temperature: +125℃.
Features
XC6SLX45T-3FGG484C features: (1)Frequency: 1.62 GHz; (2)Number of Pins: 484; (3)RoHS Compliant; (4)RAM Memory Size: 267263 B.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 XC6SLX45T-3FGG484C |
|
IC FPGA SPARTAN 6 43K 484FGGBGA |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
XC6S-9601 |
Omron Electronics |
DIN 41612 Connectors CONNECTOR |
Data Sheet |
|
|
||||||||||||
|
XC6SLX100-2CSG484C |
|
IC FPGA SPARTAN 6 101K 484CSGBGA |
Data Sheet |
|
|
||||||||||||
|
XC6SLX100-2CSG484I |
|
IC FPGA SPARTAN 6 101K 484CSGBGA |
Data Sheet |
|
|
||||||||||||
|
XC6SLX100-2FG484I |
|
IC FPGA SPARTAN 6 484FGGBGA |
Data Sheet |
|
|
||||||||||||
|
XC6SLX100-2FG676I |
|
IC FPGA SPARTAN 6 676FGGBGA |
Data Sheet |
|
|
||||||||||||
|
XC6SLX100-2FGG484C |
|
IC FPGA SPARTAN 6 101K 484FGGBGA |
Data Sheet |
|
|
||||||||||||
